Rear bumper bracket “US” left or right 74-85 Fiat 124 Spider

SKU 4022 Kategorien body, body rear, bumpers

€57,87

Delivery Time: available immediately

Deliveries to non-EU countries may incur additional duties, taxes and fees.

CS / DS
74 – 85
Rear bumper bracket “US” left or right

To change the left bumper holder it is necessary to remove the tank. Proceed as follows:

Loosen the 4 nuts on the tank.
Remove the fender corner.
Remove the fuel filler hose cover.
Remove the hose clamp at the bottom of the filling hose.
Now you can push the tank aside and loosen the fastening screw of the bumper holder.
Replace the bumper holder and reassemble everything in reverse order.

Additional information

Weight	1,5 kg
Suitable for model Fiat 124	CS-1 1800 Bj. 74-78 Carburetor, CS-2 2000 Bj. 79-80 Carburetor, CS-0 2000 Bj. 80-82 Carburetor, DS 2000 Bj. 83-85 Injection
